Pneumatic Seeder Pneusej FT1 (3-4m)
- Home
- New Machinery
- Farming Equipment
- Seeding Equipment
- Pneumatic seed drills
- Pneumatic Seeder Pneusej FT1 (3-4m)
| Make: | Pneusej |
| Model: | FT1 |
| Working Width: | 3 m ; 4 m |
| Seed Tank Volume: | 1100 (l) |
| Operating Speed: | 5-12 km/val. |
| Required power: | 110 HP; 150 HP |
| Weight : | 480 kg |
Seed drill FT1 have two possibilities:
Front tank FT1 – for seeding is a front mounted seed hopper with capacity 1100 liters, combined with rear mounted coulters. It is possible to add the hopper capacity for another 600 liters. The rear part is produced in working width 3 m – 4 m.
Front tank FT1 – for fertilizer is a front mounted hopper designed as a fertilizer tank with a combination with precision planters (max. 8 rows) and with machines for soil tillage up to 6 m working width. Hopper surface as well as parts of dosing unit are produced to withstand different types of fertilizer.
|
Model |
FT1 300 |
FT1 400 |
|
Working width (m) |
3 |
4 |
|
Transport width (m) (m) |
3 |
3 |
|
No. of rows (pc) |
20/24 |
24/28/32 |
|
Row spacing (cm) |
15/12,5 |
16,7/14,3/12,5 |
|
Hopper (l) |
1100 + 600 |
|
|
Coulters |
DXD RCI |
|
|
Coulter pressure (kg/pc) |
35 |
|
|
Depth adjustment |
Centrally / hydraulically |
|
|
Fan drive |
1000 RPM or hydraulic drive |
|
|
Weight without seed (kg) |
480 |
|
|
Weight of coulters without seed (kg) |
580 |
640 |
|
Power required (HP) |
110 |
150 |
|
Power required (kW) |
82 |
111 |
|
Working speed (km/h) |
5-12 |
|
|
Efficiency (ha/h) |
1,5-3,8 |
2,2-4,5 |
|
Connection via lower link |
Cat. III |
|
|
Feed opening (m) |
2,17x1,11 |
|
|
Filing height (m) |
1.6 |
|
|
Track tillers of seed drill (ks) |
2x2 |
|
|
Tires |
23x85-12 |
|
