Make: | Pneusej |
Model: | Fantom 300; 400; 450; 500; 600 |
Working Width: | 3 m; 4 m; 4,5 m; 5 m; 6 m |
Suspension type: | Coupled |
Seeding Equipment Type: | Disc |
Distance Between Rows: | 12,5 cm |
Operating Speed: | 10-18 km/val. |
Control Computer: | Available |
Required power: | 75-190 HP |
Tires: | 31x15,5-15 |
Seed drill designed for achieving maximum efficiency. Pneusej Fantom is designed to minimize working operations and to place the seed with maximum precision. Passive soil preparation allows higher working speed and work with large amount of crop residue. Thanks to equal weight distribution on pneumatic roller, the surface of the soil is straightened and equally compacted. One pass perfectly prepares seed bed. Pneusej Fantom creates equal conditions for every single seed.
The seed drill is designed for medium and large farmers. In this moment we offer this seed drill in working versions 3 – 4 – 4,5 – 5 – 6 meters. The big advantage are the working discs. We offer the working disc in 460 or 510 mm version. The hopper is by all version 3400 liters, but it possible to extending the hopper about 1400 liters for fertilization. If the customer decides to fertilize, he has to variants – fertilization before front working disc or behind sowing coulters. A big advantage is also the sowing coulters, which are attached to rubber silentblocks, which ensures a pressure on the sowing coulter up to 120 kg/coulter.
Technical parameters |
Fantom 300 |
Fantom 400 |
Fantom 450 |
Fantom 500 |
Fantom 600 |
Working width (m) |
3 |
4 |
4,5 |
5 |
6 |
Transport width (m) |
3 |
||||
No. of rows (pc) |
18/24 |
24/32 |
36 |
30/40 |
36/48 |
Row spacing (cm) |
16,7/12,5 |
16,7/12,5 |
12,5 |
16,7/12,5 |
16,7/12,5 |
Hopper (l) |
3400 |
||||
Coulters |
disc DD |
||||
Coulter pressure |
max. 120 kg |
||||
Depth adjustment |
Centrally / hydraulically |
||||
Fan drive |
1000 RPM or hydraulic drive |
||||
Weight without seed (kg) |
3520 |
4950 |
5450 |
6150 |
7200 |
Power required (HP) |
100 - 140 |
130 - 170 |
150 - 190 |
180 - 230 |
200 - 260 |
Power required (kW) |
75 - 105 |
95 - 125 |
110 - 140 |
130 - 170 |
150 - 190 |
Working speed (km/h) |
10 - 18 |
||||
Disc for soil preparation (ø) |
Ø 460 mm or Ø 510 mm |
||||
Efficiency (ha/h) |
2,4 - 4,3 |
3,2 - 5,8 |
3,6 - 6,5 |
4,0 - 7,2 |
4,8 - 8,6 |
Connection via lower link |
Cat. III |
||||
Feed opening (m) |
2,73x 0,97 |
||||
Filling height (m) |
2,6 |
||||
Tires |
31 x 15,5 - 15 |
